Chipset: Intel® B760 / Processor socket: Base 1700 / Memory support: 4x DDR5 / Form factor: ATX
| Serie - Mainboards | ||
| Serie | Asus TUF Serie | |
| Mainboard-Grundeigenschaften | ||
| Hersteller | ASUS | |
| Chipsatz | Intel® B760 | |
| Formfaktor | ATX | |
| BIOS Typ | 128 Mb Flash ROM, UEFI AMI BIOS | |
| Abmessungen | (ATX) 305 mm × 244 mm | |
| Mainboard-Prozessor | ||
| Prozessorfamilie | Intel | |
| Prozessorsockel | Sockel 1700 | |
| Unterstützte Prozessoren | 13th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold & Celeron® | |
| Mainboard-Speicher | ||
| Zahl der DIMM Slots | 4x | |
| DIMM-Format | 288-pin DIMM | |
| Maximaler Hauptspeicher | 128 GB | |
| Speichertyp | DDR5 | |
| Non-ECC, Un-buffered | Ja | |
| Mainboard-Erweiterungsslots | ||
| PCI-Express x16 (gesamt) | 2x | |
| PCI-Express 5.0 x16 | 1x | |
| PCI-Express 3.0 x16 | 1x | |
| PCI-Express x1 | 2x (3.0) | |
| M.2 | 3x | |
| Mainboard-Externe Anschlüsse | ||
| DisplayPort | 1x | |
| HDMI | 1x | |
| USB 3.1 Type-A | 3x | |
| USB 2.0 | 1x | |
| Ethernet (LAN) | 1 x | |
| 3,5mm Klinke | 5x | |
| Toslink/S/PDIF (optisch) | Ja | |
| Mainboard-Interne Anschlüsse | ||
| SATA 6 GB/s | 4x | |
| USB 3.2 Header | 1x | |
| USB 3.1 Header | 1x (Gen1) | |
| USB 2.0 Header | 2 x | |
| Thunderbolt 4 | Ja | |
| TPM-Header | Ja | |
| Chassis Intrusion-Header | Ja | |
| RAID | 0/1/5/10 | |
| Stromanschlüsse | 1x 24-Pin ATX, 1x 8-Pin EPS12V, 1x 4-Pin ATX12V | |
| Audiokanäle | 7.1 | |
| Audio-Codec | Realtek 7.1 Surround Sound High Definition Audio CODEC | |
| Mainboard-Kühlung | ||
| CPU-Lüfter 4-Pin | 2x | |
| Gehäuselüfter 4-Pin | 4x | |
| Pumpe 4-Pin | 1x | |
| Mainboard-Beleuchtung | ||
| RGB-Header 4-Pin | 1x | |
| ARGB-Header 3-Pin | 3x | |
| Beleuchtungsfarbe | RGB | |
| LED Kompatibilität | ASUS Aura Sync | |
| Mainboard-Netzwerk | ||
| Transferrate | 10/100/1000/2500 Mb/s | |
| WLAN | 802.11a/b/g/n/ac/ax | |
| Bluetooth | 5.2 | |
| Mainboard-Besonderheiten | ||
| M.2-Passivkühler | Ja | |
| Diagnostic LED | Ja | |
| IO-Blende integriert | Ja | |
| Backplate | Ja | |
| Audio+solid capacitors | Ja | |
| Zustand | ||
| Artikelzustand | Neu | |
