Intel® Core™ Ultra 9 275HX | bis zu 5,40 GHz (P-Core) / 4,60 GHz (E-Core) Taktfrequenz / 0 MB DDR5 RAM | M.2 SSD / NVIDIA GeForce RTX 5070 ( 8 GB ) / Barebone ( Ultra Small Form Faktor ) / WiFi 7 (802.11be) | Bluetooth 5.4 / HDMI 2x | Displayport 2x / USB 4.0 1x | USB 3.2 – 10Gb/s 4x | 2x USB 3.2 – 5Gb/s | 1x (10Gb/s) USB Typ-C / Ohne Betriebssystem
| Serie - PC-Systeme | ||
| Produktkategorie | Barebone | |
| PC-Prozessor | ||
| Bezeichnung | Intel® Core™ Ultra 9 | |
| Typ | 275HX | |
| Taktfrequenz | 2,70 GHz (P-Core) / 2,10 GHz (E-Core) | |
| Autom. Übertaktung (bis zu) | 5,40 GHz (P-Core) / 4,60 GHz (E-Core) | |
| Kerne/Threads | 8 (P-Core) + 16 (E-Core)/24 | |
| NPU | 8 TOPS | |
| L3-Cache | 36 MB | |
| TDP (Thermal Design Power) | 55 Watt | |
| Technologie | Intel® Turbo Boost Max-Technik 3.0 | |
| "Arrow Lake" | ||
| CPU - Hersteller | Intel | |
| Kühlung | luftgekühlt | |
| Mainboard | ||
| Chipsatz | Intel® System-on-Chip | |
| PC-Grafik | ||
| Modell | NVIDIA | |
| GeForce RTX 5070 | ||
| Speicher | 8 GB | |
| Speichertyp | GDDR7 | |
| DirectX | 12 | |
| HDMI-Anschluss | 2x | |
| DisplayPort-Anschluss | 2x | |
| 4K-Unterstützung | Ja | |
| Maximale Auflösung | 7680x4320@60Hz (Displayport 2.1) | |
| HDMI-Audio | Ja | |
| Plug-In Karte | Ja | |
| Arbeitsspeicher | ||
| Größe | 0 MB | |
| DDR5 | ||
| Taktung | 5600 MHz | |
| Formfaktor | SODIMM | |
| Verbaut | 0 von 2 | |
| max. Erweiterung auf | 96 GB | |
| Speicher | ||
| Format | M.2 | |
| Typ | SSD | |
| Besonderheit | 1x M.2/M-Key (PCIe x4 Gen5, 2280), 1x M.2/M-Key (PCIe x4 Gen4 2280) | |
| Laufwerk | ||
| ohne Laufwerk | ||
| PC-Eigenschaften | ||
| Gehäusetyp | Ultra Small Form Faktor | |
| Höheneinheiten | Slim | |
| Gewicht | 3.12 kg | |
| Netzteil (Leistung) | 330 Watt | |
| Sound | 5.1 onBoard | |
| Eingabegeräte | ||
| Tastatur | Nein | |
| Maus | Nein | |
| PC-Schnittstellen | ||
| LAN (RJ-45) | 1x 2.5 GBit | |
| W-LAN | WiFi 7 (802.11be) | |
| Bluetooth | 5.4 | |
| USB 3.2 Gen1 - 5Gb/s (USB 3.0) | 2x | |
| USB 3.2 Gen2 - 10Gb/s | 4x | |
| USB 4.0 | 1x | |
| USB Typ-C | 1x (10Gb/s) | |
| Thunderbolt 4 | 1x | |
| Line-In | Ja | |
| Line-Out | Ja | |
| Mikrofon | Ja | |
| Front-/Seitenanschlüsse | ||
| Audio | Ja | |
| USB 3.2 Gen2 - 10Gb/s | 3x (1x Typ-C) | |
| interne Steckplätze | ||
| DIMM | 2x | |
| PCI-Express x4 | 3x | |
| M.2 | 3x | |
| Betriebssystem/Software | ||
| Betriebssystem | Ohne Betriebssystem | |
| Office enthalten | nein | |
| PC-Abmessungen | ||
| Abmessungen | (BxHxT) | |
| Breite | 5.65 cm | |
| Höhe | 28.24 cm | |
| Tiefe | 18.77 cm | |
| Gewicht | 3.12 kg | |
| Zustand | ||
| Artikelzustand | Neu | |
