Chipset: / Processor base: / Memory support: 8x DDR4 / Form factor: E-ATX
| Mainboard-Grundeigenschaften | ||
| Hersteller | ASUS | |
| Formfaktor | E-ATX | |
| Besonderheit | WRX80 | |
| Abmessungen | (EEB) 305 mm × 330,2 mm | |
| Mainboard-Prozessor | ||
| Prozessorfamilie | AMD | |
| Unterstützte Prozessoren | AMD Ryzen Threadripper Pro 3rd Gen | |
| Mainboard-Speicher | ||
| Zahl der DIMM Slots | 8x | |
| Speichertyp | DDR4 | |
| Non-ECC, Un-buffered | Ja | |
| unterstützter Speichertakt | 2133,2400,2666,2800,2933,3000,3200 MHz | |
| Mainboard-Erweiterungsslots | ||
| PCI-Express x16 (gesamt) | 7x | |
| M.2 | 3x | |
| Mainboard-Externe Anschlüsse | ||
| USB 3.2 Type-C | 2x | |
| USB 3.2 Typ A | 8x | |
| Ethernet (LAN) | 2 x | |
| 3,5mm Klinke | 5x | |
| Toslink/S/PDIF (optisch) | Ja | |
| Mainboard-Interne Anschlüsse | ||
| SATA 6 GB/s | 8x | |
| USB 3.2 Header | 2x | |
| USB 2.0 Header | 2 x | |
| TPM-Header | Ja | |
| RAID | 0/1/5/10 | |
| Stromanschlüsse | 1 x 24-pin EATX, 2 x 8-pin ATX 12V, 1 x 6-pin PCIe | |
| Audiokanäle | 7.1 | |
| Mainboard-Netzwerk | ||
| LAN Controller | Intel® X550-AT2 | |
| Transferrate | 10/100/1000/2500 Mb/s | |
| WLAN | Wi-Fi 6E (WLAN 802.11a/b/g/n/ac/ax) | |
| Bluetooth | 5.3 | |
| Mainboard-Besonderheiten | ||
| USB BIOS Flashback | Ja | |
| Diagnostic LED | Ja | |
| Multi-GPU | NVIDIA 3-Way-SLI, AMD 3-Way-CrossFireX | |
| Zustand | ||
| Artikelzustand | Neu | |
