Intel® CoreTM 3 100U | up to 4.70 GHz (P-Core), 3.30 GHz (E-Core) clock frequency / 0 MB DDR5 RAM | M.2 SSD+HDD / Intel® Arc Graphics ( ) / Barebone (Ultra Small Form Factor) / WiFi 6E (802.11ax) | Bluetooth 5.3 / HDMI 2x | Displayport 2x / USB 4.0 2x | USB 3.2 – 10Gb/s 3x | USB 3.2 – 5Gb/s | 1x USB 2.0 / Without operating system
| Serie - PC-Systeme | ||
| Produktkategorie | Barebone | |
| PC-Prozessor | ||
| Bezeichnung | Intel® Core™ 3 | |
| Typ | 100U | |
| Taktfrequenz | 1,20 GHz (P-Core) / 0,90 GHz (E-Core) | |
| Autom. Übertaktung (bis zu) | 4,70 GHz (P-Core), 3,30 GHz (E-Core) | |
| Kerne/Threads | 2 (P-Core) + 4 (E-Core)/8 | |
| L3-Cache | 10 MB | |
| TDP (Thermal Design Power) | 15 Watt | |
| Technologie | Intel® Turbo-Boost-Technik 3.0 | |
| Intel® Hyper-Threading-Technologie | ||
| "Raptor Lake-Refresh" | ||
| CPU - Hersteller | Intel | |
| Kühlung | luftgekühlt | |
| PC-Grafik | ||
| Modell | Intel® | |
| Arc Graphics | ||
| DirectX | 12 | |
| HDMI-Anschluss | 2x | |
| DisplayPort-Anschluss | 2x | |
| 4K-Unterstützung | Ja | |
| Maximale Auflösung | 7680x4320@60Hz (Displayport 1.4) | |
| HDMI-Audio | Ja | |
| Arbeitsspeicher | ||
| Größe | 0 MB | |
| DDR5 | ||
| Taktung | 5600 MHz | |
| Formfaktor | SODIMM | |
| Verbaut | 0 von 2 | |
| max. Erweiterung auf | 96 GB | |
| Speicher | ||
| Format | M.2 | |
| Typ | SSD+HDD | |
| Besonderheit | PCIe x4 Gen 4: M.2 22x80 (key M) NVMe SSD / PCIe x4 Gen4: M.2 22x42 (key M) NVMe SSD / SATA 2.5" SSD | |
| Laufwerk | ||
| ohne Laufwerk | ||
| PC-Eigenschaften | ||
| Gehäusetyp | Ultra Small Form Faktor | |
| Höheneinheiten | Tall | |
| Wandmontage | Ja | |
| Gewicht | 0.57 kg | |
| Netzteil (Leistung) | 90 Watt extern | |
| Sound | onBoard | |
| PC-Schnittstellen | ||
| LAN (RJ-45) | 1x 2.5 GBit | |
| W-LAN | WiFi 6E (802.11ax) | |
| Bluetooth | 5.3 | |
| USB 2.0 | 1x | |
| USB 3.2 Gen2 - 10Gb/s | 3x | |
| USB 3.2 Gen 2x2 - 20Gb/s | 1x (Typ-C) | |
| USB 4.0 | 2x | |
| Thunderbolt 4 | 2x | |
| Line-In | Ja | |
| Line-Out | Ja | |
| Mikrofon | Ja | |
| Front-/Seitenanschlüsse | ||
| Audio | Ja | |
| USB 3.2 Gen2 - 10Gb/s | 2x | |
| interne Steckplätze | ||
| DIMM | 2x | |
| PCI-Express x1 | 1x | |
| PCI-Express x4 | 1x | |
| S-ATA | 1x | |
| M.2 | 2x | |
| 2,5" Schacht | 1x | |
| Betriebssystem/Software | ||
| Betriebssystem | Ohne Betriebssystem | |
| Office enthalten | nein | |
| PC-Abmessungen | ||
| Abmessungen | (BxHxT) | |
| Breite | 11.7 cm | |
| Höhe | 5.4 cm | |
| Tiefe | 11.2 cm | |
| Gewicht | 0.57 kg | |
| Zustand | ||
| Artikelzustand | Neu | |
